High-strength Yuchai Engine Silent Type Genset

hae

ISO 8528: Hoʻonohonoho hoʻonohonoho generator AC i hoʻohuli ʻia e ka ʻenekini kuni kūloko

IEC 60034-1: Nā koina loea e pono ai no ka hoʻohuli ʻana i nā mīkini uila

YD / T 502: Hoʻonohonoho hoʻonohonoho diesel generator

GB / T 20136-2006: Ke ʻano hoʻāʻo laulā no ke kahua uila ʻenekini puhi kūloko

KEKAHI

The main structure of the engine body, cylinder head, crankshaft and connecting rod has been tested for a long time to ensure the high reliability of the whole machine.

Adopt the cylinder head integrated water outlet design to reduce the sealing surface and improve the reliability of the sealing.

Leading turbocharged and intercooled, four-valve and electronic control technology, the combustion organization is accurate and rapid, the emission is good, the transient response performance is good, and the loading capacity is strong.

The high-strength cylinder block, alloy crankshaft, alloy steel connecting rod and internal cooling oil passage piston make the engine more durable, and it has a lighter and more compact structure among similar products.

Adopt advanced and mature BOSCH electronic control common rail with high-efficiency supercharging technology to accurately control the fuel injection volume and sufficient air intake to ensure that the diesel engine can fully burn and emit less under different load conditions.

Good transient speed regulation and strong loading capacity.

E hoʻokō i nā koi o ka pae hana G3 o ka generator set.

The transient response of the unit is tested according to the ISO 8528-5 standard, and the single-step loading rate can reach up to 60%
All engine systems have passed prototype and factory tests

The use of excellent shock absorption devices can reduce the vibration of the unit, and the use of high-efficiency silencers and a fully enclosed noise reduction system can reduce the noise of the unit by 15 to 35dB (A), making the unit less vibration and low noise.

Hoʻohana i ka hoʻolālā ʻana o ka labyrinth air duct a me ka hoʻolālā ʻupena pale lepo, a me ka hoʻohui ʻana i nā ʻāpana sila a me ka hoʻopili ʻana i ka sealant e kaulike i nā pono like ʻole o ka ea a me ka wai a me ka pale lepo. I ka manawa like, ua hōʻoia ʻia e ka hoʻāʻo ʻana i ka ua a me ka hoʻāʻo lepo lepo. ʻO ka pae palekana maʻamau ʻo IP23. Hiki ke kiʻekiʻe loa i IP43.

The use of high-quality steel and surface spray treatment, corrosion resistance, scratch resistance and rust resistance, strong and durable.

Auana

KANAWAI

ʻĀINA HANA

ʻO ka mana nui (PRP) ka mana nui e hiki ai i ka anakahi ke hoʻomau i ka hana me ka loli loli ma lalo o ke kaiapuni maʻamau (kaomi o ka lewa, ka wela e pili ana, ka mahana wela) a ʻae i ka hana ʻo 10% overload no 1 hola i kēlā me kēia 12 hola.

Kiʻekiʻena: ≤1000m (ke> 1000m, koi ʻia ka hoʻoponopono mana)

Ka mahana wela: 40 ° C (ke> 40 ° C, koi ʻia ka hoʻoponopono mana)

Hulu pili pili: ≤60%

Ke kū ʻole nā ​​kūlana hana ma ka pūnaewele o ka diesel e hana ana i nā kūlana i luna, pono e hoʻoponopono i ka mana puka o ka hoʻonohonoho generator, a ma ka hope loa e hoʻoponopono i ke kolamu, e nīnau mai iā mākou.
